PURE WHITE 1:1 HD
INCH SERIES
Part: HM212049/HM212011 Scale: Standardized 800×800
Tapered Roller Bearings (Inch Series) American Inch Heavy Duty Series
✓ Ready for Ontario Will-Call
HM212049/HM212011
Inch Tapered Roller Bearing Set HM212049/HM212011
American inch series matched cone and cup tapered roller bearing assembly (HM212049/HM212011) engineered for heavy truck wheel ends, highway trailer axles, and agricultural machinery in Canada.
ENGINEERING SPECIFICATION PARAMETERS
| Specification | Value / Engineering Metric |
|---|---|
| bore d | 2.6250 in (66.675 mm) |
| outer D | 4.8125 in (122.238 mm) |
| assemblyWidth T | 1.5000 in (38.100 mm) |
| coneWidth B | 38.354 mm |
| cupWidth C | 29.718 mm |
| coneCupSet | HM212049/HM212011 |
| dynamicRating Cr | 209 kN |
| staticRating Cor | 279 kN |
| limitingSpeedGrease | 3200 RPM |
| limitingSpeedOil | 4300 RPM |
| weight | 1.84 kg |
| Material Grade | Case-Carburized Heavy Duty Alloy Steel |
| Industry Standards | ABMA Standard 19.2 · ANSI / SAE Heavy Duty · Timken Standard |
| Working Pressure | Dynamic Rating 209 kN / Static 279 kN |
| Temperature Range | -40°F to +250°F (-40°C to +121°C) |
| Warehouse Fulfillment | Mississauga Dock Will-Call or Canadian Courier Dispatch |
B2B WHOLESALE PRICINGRequest Formal Quote
In StockWholesale prices are tier-based depending on order volume. KZL sales engineers provide firm quotes within one business hour.
Need urgent same-day pickup in Mississauga?Direct Sales Desk: +1 (647) 886-0087
