PURE WHITE 1:1 HD
INCH SERIES
Part: JL69349/JL69310 Scale: Standardized 800×800
Tapered Roller Bearings (Inch Series) American Inch Heavy Duty Series
✓ Ready for Ontario Will-Call
JL69349/JL69310
Inch Tapered Roller Bearing Set JL69349/JL69310
American inch series matched cone and cup tapered roller bearing assembly (JL69349/JL69310) engineered for heavy truck wheel ends, highway trailer axles, and agricultural machinery in Canada.
ENGINEERING SPECIFICATION PARAMETERS
| Specification | Value / Engineering Metric |
|---|---|
| bore d | 1.4961 in (38.000 mm) |
| outer D | 2.4803 in (63.000 mm) |
| assemblyWidth T | 0.6693 in (17.000 mm) |
| coneWidth B | 17.000 mm |
| cupWidth C | 13.500 mm |
| coneCupSet | JL69349/JL69310 |
| dynamicRating Cr | 39.8 kN |
| staticRating Cor | 55.0 kN |
| limitingSpeedGrease | 6000 RPM |
| limitingSpeedOil | 8000 RPM |
| weight | 0.19 kg |
| Material Grade | Case-Carburized Heavy Duty Alloy Steel |
| Industry Standards | ABMA Standard 19.2 · ANSI / SAE Heavy Duty · Timken Standard |
| Working Pressure | Dynamic Rating 39.8 kN / Static 55.0 kN |
| Temperature Range | -40°F to +250°F (-40°C to +121°C) |
| Warehouse Fulfillment | Mississauga Dock Will-Call or Canadian Courier Dispatch |
B2B WHOLESALE PRICINGRequest Formal Quote
In StockWholesale prices are tier-based depending on order volume. KZL sales engineers provide firm quotes within one business hour.
Need urgent same-day pickup in Mississauga?Direct Sales Desk: +1 (647) 886-0087
